Long-life Battery-Powered Global GPS Tracker
The best international shipping container GPS tracker is for long-term asset tracking, tamper detection, and theft recovery!
The Oyster3 Global is a long-life, ultra-rugged battery-powered GPS device designed for global asset tracking applications. It offers cellular 4G LTE Cat 1bis with 2G fallback for seamless global connectivity, adaptive tracking technology for energy conservation, waterproof and rugged IP68 housing, and user-replaceable Energizer Lithium batteries, ensuring 8+ years of life.
Impact, theft recovery alerts, and flexible configurations for various tracking applications. Track your flat racks, shipping containers, trailer tracking, international freight and other assets where super-long battery life is required without sacrificing the frequency of updates or performance. With 2G fallback, enabling seamless global tracking and asset management.
The IP-68-rated housing is rugged and UV-stable, so the Oyster 3 Global can be mounted on assets exposed to rain, dust, and marine conditions.
Global Asset Tracking Application
The Oyster 3 Global offers real-time tracking and can operate in ultra-low power modes by utilising the latest technology, including asset tracking software. With an incredible battery life of up to 4 years, the Oyster Global can be attached to assets and tracked without changing batteries. The Oyster 3 Global has built-in antennas for GPS reception, a 3D accelerometer, a high-performance GPS that can track using GPS and GLONASS satellites simultaneously, and flash memory for storing non-volatile information.
Container GPS Tracker
The Oyster 3 uses 3 x AA 1.5V “off-the-shelf” lithium batteries. These are available at retail outlets from manufacturers like Energizer. Industrial 1.5V Lithium AA batteries are also available.
Energizer Lithium batteries have excellent performance and capacity, allowing the Oyster 3 Global to operate in extreme temperatures and climatic conditions that other tracking devices cannot.
FEATURES
- There are no lock-in contracts; track it 24/7 with our app.
- No installation is required. Simply “place ‘n trace.”
- Deploy-once battery life of up to 8+ years on only 3 x AA user-replaceable batteries, once daily location.
- Powered by off-the-shelf Energizer Lithium batteries
- Tracks assets when they’re on the move and enters sleep mode when stationary to save power
- Weatherproof and ultra-rugged IP67 Nylon Glass Housing
- Geofencing for simple real-time alerts on movements
- “Battery Low” and “Battery Critical” alerts
- LTE Cat 1bas /2G Connectivity
- Unauthorised movement alert
- Accelerometer for Smart Movement-Based Tracking
- Dimensions: 108 x 86 x 31 mm (4.25 x 3.39 x 1.22”)
Take control of your assets with the Oyster 3 Global. Experience the power of long-life battery-powered GPS tracking.
Applications
- Equipment location and recovery
- Non-powered asset tracking
- Shipping containers and freight
- International shipments
- Global SIM card for overseas deployment
- 2G Migration - Operates on current 2G networks with a migration path to 4G when /if 2G networks are shut down
Download The Keep Track GPS Telematics App for IOS or Android!
-
Specifications Oyster3 Global GPS Tracker
CONNECTIVITY
Cellular Module Ublox LENA R8 Modem operates on all major global 4G Cat 1bis and 2G bands Supported 4G Cat 1bis bands: B1, B2, B3, B4, B5, B7, B12, B20, B28, B38, B40, B41, B66 Location
GNSS Module Ublox LENA-R8001M10 Constellation Concurrent GPS/QZSS, GLONASS, Galileo, BeiDou Tracking Sensitivity -148 dBm cold start / -159 dBm hot start *Location Accuracy ~1m 2D RMS, GPS, -130dBm GNSS Assistance GNSS almanac and ephemeris data for greater sensitivity and position accuracy Low Noise Amplifier GPS signals are filtered and boosted by a SAW filter and low-noise amplifier (LNA) allowing operation where other units fail Cell Tower Location Cell tower location fallback for positioning when GPS can't get a fix * The GNSS supplier provides positioning accuracy specifications that reflect ideal conditions. However, device configuration, installation, environmental conditions, augmentation services, and many other factors may lead to variations in positioning accuracy.
Power
Input Voltage 3.8 V – 16 V DC 10uA*
*Average current in lowest power configurationSafety Reverse Polarity Protection Batteries
User-Replaceable Batteries 3 x AA. Batteries are not included. Supported Battery Types Lithium (LiFeS2) or Lithium Thionyl Chloride (LTC)
*Please dispose of Lithium batteries safely and responsibly*Battery Life Estimates Once Daily location updates – 8 years
**Movement-Based location updates – 2.5 years
Hourly location updates – 1.5 years* Several factors, including temperature, installation and orientation of the device, the frequency of location updates, network coverage, sensor integrations, peripherals, accelerometer settings, and more, influence battery life estimates.
** Movement-based estimates are based on 2 hours of movement, occurring 5 days a week, with default tracking parameters (location updates every 3 minutes and uploads every 30 minutes). Devices can be configured to provide more frequent location updates when the asset is in motion.
Mechanics / Design
Dimensions 108 x 86 x 30 mm Weight 120g IP/IK Rating The device's ultra-rugged, waterproof IP68 housing ensures it can withstand impact, fine dust, and brief submersion. Installation Compact and concealable. Multiple installation options for covertly and easily securing the device to assets with screws, bolts, cable ties, rivets, and more. Stainless steel screws provided. Operating Temperature -30°C to +60°C- For operation in extreme temperatures, use LTC Batteries Cellular Antenna Internal GPS Antenna Internal 3-Axis Accelerometer 3-Axis Accelerometer to detect movement, high G-force events, and more Diagnostic LED Diagnostic LED indicates the operation status. Flash Memory Store weeks of records if the device is out of cellular coverage. Storage capacity for over 4 weeks of continuous 2-minute logging. Onboard Speed and Heading Current speed and heading is reported with each position update. Onboard Temperature The device reports internal temperature, which indicates ambient temperature but may not always be precise. Smarts
Configure parameters to send updates based on set time intervals or when movement occurs.
Adaptive tracking technology detects when the device is on the move and increases the update rate,
providing detail when you need it while conserving battery when stationary.Battery Life Monitoring 'Battery Low' and 'Battery Critical' alert levels Geofence Alerts The server can use device location to create geofences and alerts if an asset enters or leaves designated locations. Onboard Geofencing Geofences can be downloaded directly to the device for enhanced location-based actions and alerts. There can be a maximum of 500 Geofences, with up to 100 points per geofence. Impact Detection Configure impact-detection alerts when a user-defined threshold exceeds G-forces Rotation Counting Keeps a count of the number of rotations of the device about the Z axis Run Hour Monitoring Capture run hours based on movement to understand and optimise asset utilisation. Sleep Mode Stationary devices enter sleep mode until movement occurs to conserve battery life and optimise data usage. Theft Recovery Switch to Recovery Mode in the case of theft or loss to activate real-time tracking for asset retrieval. Tip Detection Define a range of angles that constitutes a 'tipped' state and configure alerts. Security Data
Data Security Military-level AES-256 Encryption from device to Device Manager to protect the integrity and confidentiality of telematics data. Data forwarded to third-party systems is sent via HTTPS for end-to-end security. Manufacturer's Warranty
Manufacturer's Warranty Two-year manufacturer's warranty. -
Download The Oyster3 Global Data Sheet
